SPECIFICATION

Main frame:
Grade 9 titanium tubes, welded main frame with cast titanium bottom bracket manifold

Headset & Stem:
Grade 9 titanium diameter tubes with integrated headset and spring loaded steerer catch hinge

Rear frame:
Advance Superlight rear frame with replaceable hanger, suspension block and 54mm roller wheels

Fork:
One piece carbon fork and steerer with magnetic pedal holder

Weight: 7.95kg

Folded Dimensions:
645mm (H) x 600mm (W) x 320mm (D) (25.4in x 23.6in x 12.6in)

Saddle:
Superlight saddle with carbon rails and base with integrated carry handle and mount

Seatpost:
Superlight seatpost with carbon core and 0.3mm steel armour. Standard length for up to 33”/84cm

Seatclamp:
Machined aluminium seat clamp and rear frame clip in anodized matt black finish

Grips: Superlight lock-on foam grips

Pedals:
Superlight cnc aluminium pedal set with left hand QR pedal

Hinge clamps:
Machined aluminium self-aligning hinge clamp levers and plates anodized matt black finish

Front Wheel:
Lightweight rim, double butted spokes and aluminium hub body with sealed bearings and allen key axle.

Rear Wheel:
Lightweight rim, double butted spokes, aluminium hub body and 4 speed freehub body

Tyres:
Schwalbe ONE with Addix race compound and v-guard puncture protection

Tubes:
Tubolito S-tubo 34g tube with presta valves

Chainset:
Superlight carbon crankset with hollow BB30 axle, integrated spider, 50T chainring and chainguard

Bottom Bracket: FSA Mega Exo Bottom Bracket

Derailleur:
Patent pending direct mount 4 speed derailleur

Sprockets: 11-13-15-18 tooth

Shifter: 4 speed trigger shifter

Chain tensioner:
Advance chain tensioner with replaceable hanger mounting

Handlebars:
31.8mm Superlight carbon low handlebar in 560mm width

Front carrier:
Large diameter front carrier block adaptor for all types of Brompton luggage

Mudguards:
Curved profile mudguards with titanium stays and rubberized flap
