Frame

Frame
Canyon Grand Canyon AL SL
Robust aluminium frame with optimal stiffness-to-weight ratio. Category: 3.
Material: Aluminium (AL)
Suspension Fork
RockShox Judy Silver
Travel: 120 mm
Axle Dimension: 15 x 110 mm
Size XS bikes: 100 mm travel

Drivetrain

Rear Derailleur
SRAM SX Eagle
SRAM SX Eagle rear derailleur provides quick and quiet shifts across 10-50 or 11-50 tooth cassettes.
Shift Lever
SRAM SX Eagle Trigger 12s
SX Eagle's 12-speed shifters offer quick and crisp gear changes.
Cassette
SRAM PG-1210 Eagle 11-50 12s
SRAM's SX Eagle 11-50 cassette packs a wide, 454% gear range into a surprisingly affordable package.
Crank
Truvativ Stylo 6K DUB 30T
Number of chainrings: 1
Bottom bracket
SRAM Pressfit DUB
Chain
SRAM SX Eagle 12s

Brakes

Disc Brake
Shimano MT400
Disc Brake
Shimano MT400
Brake Rotor
Shimano RT10
Shimano's 180mm RT10 rotor provides a good balance of stopping power and modulation.
Brake Rotor
Shimano RT10
Rotor diameter: 160 mm.

Wheels

Wheel
Alexrims MD25 | Shimano MT400
Rotor Mount: Center Lock
Wheel
Alexrims MD25 | Shimano MT400 SH11
Rotor Mount: Center Lock
Tyre
Schwalbe Rapid Rob 2.25''
Casing: K-Guard
Tyre
Schwalbe Tough Tom 2.25"
Thru Axle
Canyon Quixle
The Canyon Quixle unites the stiffness of a through axle with the ease-of-use of a quick release.
Material: Aluminium
Built-in dimension: 12 x 148 mm
Lever: Integrated

Cockpit

Stem
Iridium
Clamping Diameter: 31,8 mm
Handlebar
Iridium Flatbar
Material: Aluminium
Rise: 5 mm
Grips
Canyon push-on Grips
Our grips for confidence building control on the bars.

Seat

Saddle
Iridium Trail
Seatpost
Iridium Dropper
This dropper post features 150 mm of stepless height adjustment, giving you more freedom to move around when things get steep.
Clamp diameter: 30,9 mm

Accessories

Flat Pedals
Iridium VP-536
Flat pedals made from robust polypropylene plastic.
Manuals and Accessories
Canyon Smallbox
Reflector Set
Quickstart Guide
Torque Wrench incl. Bit-Set
Pedal Wrench
Shock Pump

Optional extras: replacement spares & wearing parts

Derailleur hangers
Derailleur Hanger GP0155-01
Seatclamps
Canyon Seatclamp
Cable routing parts
Canyon GP7037-01 Cable Routing Kit
Mounting hardware
Canyon GP7025-01 Bottleholder Screws
Cable routing parts
Canyon GP7235-01 Cable Routing Kit
Brake Pad
Shimano B05S Organic Brake Pads for Deore & Alivio
